UnaShield has four Arduino standard headers (pin connectors): one 6-pin header, two 8-pin headers, and one 10-pin header.

#Arduino uno pinout gnd serial#

The Sigfox modules may be controlled via the UART interface with serial terminal commands (similar to the AT Command Format used by modems). UnaShield V1(A) embeds a Radiocrafts Sigfox module RC1692HP-SIG, certified for RCZ2 and RCZ4 UnaShield V2 / V2S uses a WISOL Sigfox module in the WSSFM10R Series, certified for all four RCZs. To prevent damage to the onboard Sigfox module, always connect the antenna before powering up the UnaShield and before sending any Sigfox messages. The SMA (SubMiniature version A) Connector is used for connecting the provided coaxial RF antenna to the UnaShield. All the Arduino pins used by the UnaShield are connected to a level-shifter to ensure that the pin voltage is always fixed at 3V3. The onboard Sigfox module works with DC 3V3 power.

Sigfox network adapter if these essential five pins are properly connected. The five pins marked by * are required for proper operation of the onboard Sigfox module.Įven though UnaShield is designed for Arduino Uno R3, the UnaShield can be integrated with another device as a.Interrupt#2 of Accelerometer INT2 (V2S2: Select by J205) Wakeup onboard module from deep sleep mode

Reset Arduino MCU & Sigfox Module；Low activeĮxtra power source input of Arduino platform RCZ4: Argentina, Australia, Colombia, Hong Kong, Malaysia, New Zealand, Singapore, Taiwan, Thailand It uses Sigfox-certified WISOL or Radiocrafts modules to support all RCZs (Radio Configuration Zones). UnaShield is an Arduino Shield with a Sigfox transceiver module that is compatible with Arduino Uno R3 and other Arduino-based development boards.
